Home >> Solution >> Reliable Low-density Cementing System ( ReliCem )
Reliable Low-density Cementing System ( ReliCem )
  • ReliCem- Application

      Ⅰ Low pressure and easily leaking formation.

      Ⅱ Cementing at surface layer, intermediate and payzone formation.

      Ⅲ Cementing in payzone with single low-density Cementing System.

      Ⅳ Cementing in horizontal well or at inclined section.

    contact us
  • ReliCem- Characteristics
      • Suitable for cementing in low temperature and easily leaking formation.
      • The specific gravity can be controlled at 1.30～1.80g/cm³, with good rheology and easy operation on site.
      • Low free liquid and reliable compressive strength of cement.
      • Good stability, good compatibility withdifferent brands and series of cement.
      • Reliable cement strength and contributing to secured cementing quality.
    contact us
Reliable Low-density Cementing System
Items Temperature（℃）
60 90 120 150 170
Density,g/cm³ 1.30 1.30 1.30 1.30 1.30
Fluidity,cm 21.0 20.0 20.0 21.0 20.5
Thickening time,min 268 365 215 320 328
Initial consistency,Bc 18 17 23 20 19
（40～100）BcTime,min 7 6 8 2 9
Free water,% 0 0 0 0 0
API Filtration,mL 16 30 20 30 24
C S(Top),MPa 5.2 14.3 19.9 22.0 8.0
C S(Bottom),MPa 26.2 15.1 14.5 16.1 15.3
Shrinkage Rate,% 0 0 0 0 0
ReliCem- Configuration
    • 60℃

    G Cement+35%CP-52+25%CP-53+0.2% GH-6 +4.0%G310+1.5%UPV+0.2%XP-1

    • 90℃

    G Cement+35%CP-52+25%CP-53+0.6% GH-6 +4.0% G310+1.0%UPV+0.2%XP-1

    • 120℃

    G Cement+35%CP-52+25%CP-53+1.0% GH-9 +5.0% G310+1.0%UPV+0.2%XP-1

    • 150℃

    G Cement+35%CP-52+25%CP-53+2.2% GH-9 +5.0% G310+1.0%UPV+0.2%XP-1

    • 170℃

    G Cement+35%CP-52+25%CP-53+35%Silicon powder +2.0% GH-9+6.0% G310

    +0.2%UPV+0.2%XP-1

ReliCem- Configuration
60℃ G Cement+35%CP-52+25%CP-53+0.2% GH-6 +4.0%G310+1.5%UPV+0.2%XP-1
90℃ G Cement+35%CP-52+25%CP-53+0.6% GH-6 +4.0% G310+1.0%UPV+0.2%XP-1
120℃ G Cement+35%CP-52+25%CP-53+1.0% GH-9 +5.0% G310+1.0%UPV+0.2%XP-1
150℃ G Cement+35%CP-52+25%CP-53+2.2% GH-9 +5.0% G310+1.0%UPV+0.2%XP-1
170℃ G Cement+35%CP-52+25%CP-53+35%Silicon powder +2.0% GH-9+6.0% G310+0.2%UPV+0.2%XP-1
Reliable low-density Cementing System
